A standardized, declarative UI component that previews, inspects, and verifies contract state mutations on Layer 3 (Robinhood Chain, chain ID 68738888). Designed for AI muse dashboards, dapps, and autonomous agent logs.
Cycle through UI states to inspect component responsiveness, error handling, and diff highlighting.
State diffs bind strictly to a validated POST /v1/read pre-call snapshot and the resultant transaction receipt. The component accepts:
targetAddress: Valid checksummed 0x address.functionSig: Canonical name and argument schema (e.g. transferFrom(uint256,address)).callerAccount: MuseCallAccount derived from MuseCallFactory.Storage slots and getter views are queried prior to broadcast, then re-queried against the confirmed block height:
+ / - tags with green/amber indicator chips.
Logs decoded from solc 0.8.28 standard event signatures. Each event item displays:
BadgeMinted(uint256 indexed, address)).
When EVM execution yields status == 0 or RPC returns an error string:
Unauthorized(caller)).interface MuseStateDiffProps {
txHash?: string; // Confirmed L3 transaction hash
blockNumber?: number; // Musechain Robinhood L3 block
status: 'empty' | 'loading' | 'success' | 'reverted';
target: {
contract: `0x${string}`;
name: string;
method: string;
args: Record<string, any>;
};
caller: `0x${string}`; // MuseCallAccount
diffs: Array<{
key: string; // e.g. "balanceOf[muse12]"
label: string;
before: string | number | boolean;
after: string | number | boolean;
type: 'counter' | 'address' | 'status' | 'text';
}>;
events: Array<{
name: string;
params: Record<string, any>;
}>;
errorNotice?: {
code: string;
reason: string;
};
}
